| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
169-171 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
10 regular @ 10 channels per second
One XTAL per channel
|
| Power supply: | 4.8 VDC (NiCd battery pack) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / Simple threads |
| Dimensions (W*H*D): | 69*112*33 mm (2.72*4.41*1.3") |
| Weight: | 240 g (8.46 oz), with battery pack |
| Other features: | Charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (No SINAD reference) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
