| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
31.180-51.655 / 151.180-171.655 / 451.180-471.655 MHz
|
| Tuning steps: | 5 KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
16 regular @ 10 channels per second
|
| Power supply: | Mains: 117 VAC (Male 2-pin jack) |
| Current drain / power consumption: | ? W |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1976-197x (Discontinued) |
| Additional info: |
This is one of the world's first keypad programmable scanners.
Introductory price 1976 in the US: $359.95
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
