| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: | 76-82 / 164-172 MHz |
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
20 regular (10 lo-band + 10 hi-band)
XTAL controlled
|
| Power supply: | 13.8 VDC (Barrel connector) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 118*42*179 mm (4.65*1.65*7.05") |
| Weight: | 740 g (1.63 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | 1 uV (No S/N reference) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 20 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1981-198x (Discontinued) |
| Additional info: |
New price 1981 in Sweden: SEK 639:-
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
