| GENERAL |
| Type: | VLF receiver |
| Frequency range: |
0.003-0.810 MHz in 5 bands
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / SSB |
| Channels / memory management: |
|
| Power supply: | Mains |
| Current drain / power consumption: | ? W |
| Antenna impedance / connector: | 50-75 ohm / ? |
| Dimensions (W*H*D): | 483*203*381 mm (19.02*7.99*15") |
| Weight: | 22 Kg (48.46 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 2.215 MHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 150 mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 19xx-19xx (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
