| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 74-84 / 159-171 / 400-420 MHz |
| Tuning steps: | Channelized
Programmable in ? KHz increments |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
16 regular
|
| Power supply: | 13.8 VDC (Barrel connector, center positive) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 149*55*192 mm (5.87*2.16*7.56") |
| Weight: | 1.02 Kg (2.25 lb), without mobile bracket |
| Other features: | Tone control. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz - Ceramic filter: Kyocera F455P 15A
|
| Sensitivity: | 0.5 uV (No reference) |
| Selectivity: | 15 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | 3.5 mm, 8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Additional info: | New price 1987 in Sweden: SEK 1970:- |
| Related documents: |
User manual (2 MB, in swenglish/svengelska)
AF amp: uPC2002
FM-IF: MC3359P
|
| Modifications: | |
| Reviews: | |
| Options / Accessories: |
|
