| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
0.52-999 MHz in 8 bands
| MW: | 0.52-1.71 MHz |
| SW: | 2.3-30 MHz |
| CB: | 25-28 MHz |
| FM: | 64-108 MHz |
| AIR: | 118-138 MHz |
| WB: | 162.4-162.55 MHz |
| VHF: | 20-250 MHz |
| UHF: | 250-999 MHz |
|
| Tuning steps: | 1 / 3 / 5 / 7.5 / 8.33 / 9 / 10 / 12.5 / 25 / 50 / 100 KHz (Depending on band) |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM / SSB (Depending on band) |
| Channels / memory management: |
200 regular
|
| Power supply: | 3.7 VDC (BL-5C Li-ion battery) |
| Current drain / power consumption: | 700 mA (Receiver only)
Max 1.4 A (MP3/Bluetooth on) |
| Antenna impedance / connector: | - / Fixed telescopic whip
Plug-in ferrite bar for MW |
| Dimensions (W*H*D): | 60*136*35 mm (2.36*5.35*1.38") |
| Weight: | 159 g (5.61 oz), with battery |
| Other features: |
Media player and recorder (MP3, WMA, WAV, APE, FLAC).
Bluetooth 5.2. MicroSD card slot (TF card) max 256 GB.
Equalizer. Attenuator. Jog wheel. USB-C for charging and
PC connection. BFO. Local/DX switch. Alarm clock and sleep
timer. App controllable
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2026-202x |
| Reset procedure: | |
| Additional info: | |
| Related documents: |
User manual (2 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
W3
|
Signal repeater with longwire antenna
|
|
