| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
68-88 / 108-174 / 380-512 / 806-960 MHz
|
| Tuning steps: | 5 / 12.5 / 25 KHz (Depending on band) |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
200 regular in 10 banks @ 25 channels per second
10 monitor
1 priority
|
| Power supply: |
7.2-9 VDC (Six R6 / AA alkaline or NiCd batteries)
or 9 VDC external (Male barrel jack, center negative)
|
| Current drain / power consumption: | Max 200 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 58*145*42 mm (2.28*5.7*1.65") |
| Weight: | 250 g (8.8 oz) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM (10 dB S/N)
108-137 MHz: 2 uV
FM (12 dB SINAD)
68-88 MHz: 1 uV
137-174 MHz: 1 uV
380-512 MHz: 1 uV
806-960 MHz: 2 uV
|
| Squelch sensitivity: | Less than 1 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 20 KHz (-6 dB)
40 KHz (-50 dB) |
| Image rejection: | |
| AF output power / speaker: | 200 mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By GRE), 1993-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
