| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
75-85 / 144-174 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
8+8 regular
XTAL controlled
|
| Power supply: | Mains: 220 VAC (2-pin connector)
or 13.8 VDC (Barrel connector) |
| Current drain / power consumption: | ? mA @ 13.8 VDC |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) or built-in telescopic whip |
| Dimensions (W*H*D): | 166*54*193 mm (6.54*2.13*7.6") |
| Weight: | 1.55 Kg (3.42 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Selectivity: | 20 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | 3.5 mm, 4-8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-198x (Discontinued) |
| Additional info: | |
| Related documents: |
FM-IF amp: TA7061AP
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
