| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
78-88 / 155-168 / 456-476 MHz
|
| Tuning steps: | Channelized
Programmable in ? KHz increments |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
16 regular
|
| Power supply: | 13.8 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 149*55*192 mm (5.87*2.16*7.56") |
| Weight: | 1.02 Kg (2.25 lb), without mobile bracket |
| Other features: | Tone control. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (No SINAD reference) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
