| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
0.1-2059 MHz
|
| Tuning steps: | 10 / 50 / 100 / 500 Hz, 1 / 5 / 6.25 / 9 / 10 / 12.5 / 20 / 25 / 30 / 50 / 100 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM / SSB |
| Channels / memory management: |
500 regular in 10 banks @ 30 channels per second
10 search banks
50 pass
1 priority
0 to 9.9 seconds programmable scan resume delay (Squelch controlled)
1 to 99 seconds scan resume delay (Pause timer controlled)
|
| Power supply: | 4.8-6 VDC (Four R6 / AA alkaline or NiCd batteries)
or 9-16 VDC external (Male barrel jack, center positive) |
| Current drain / power consumption: | 95 mA (Squelched) |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 64*153*39 mm (2.52*6.02*1.54") |
| Weight: | 310 g (10.9 oz), with batteries |
| Other features: |
Attenuator (~10 dB). Sleep timer. Data cloning.
RS-232C option.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
AM (10 dB S/N)
0.53-2 MHz: 10 uV
2-10 MHz: 12 uV
10-400 MHz: 0.8 uV
FM (12 dB SINAD)
10-400 MHz: 0.5 uV
400-1000 MHz: 0.7 uV
1000-1300 MHz: 1.5 uV
WFM (12 dB SINAD)
10-1000 MHz: 6 uV
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 110 mW at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 199x-199x (Discontinued) |
| Reset procedure: |
On the left side is a small hole with a recessed reset switch. With the power
on, momentarily press the switch with a non-conductive stick or similar to
soft reset the CPU. Your memory and search bank data will remain.
You may also soft reset the CPU by holding the [CLR] key while powering
on the radio. It's a different method but with the same result as above.
|
| Additional info: | |
| Related documents: |
User manual (467 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
