| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
0.15-1.62 / 1.711-30 / 76-108 MHz
|
| Tuning steps: |
LW: 9 / 10 KHz
MW: 1 / 9 / 10 KHz
SW: 1 / 15 KHz
WFM: 10 / 50 KHz
|
| Frequency stability: | ? ppm |
| Mode: | AM / SSB / WFM (Stereo) |
| Channels / memory management: |
1000 regular
Scanning
|
| Power supply: | 6 VDC (Four LR6 / AA batteries)
or 6 VDC external (Male barrel jack, center positive) |
| Current drain / power consumption: | 150 mA (Average) |
| Antenna impedance / connector: |
? ohm / TS "Minijack" (3.5 mm)
Built-in telescopic whip
Built-in ferrite bar (LW/MW) |
| Dimensions (W*H*D): | 205*129*40 mm (?") |
| Weight: | 570 g (? lb), without batteries |
| Other features: |
DX/Local switch. Narrow/Wide switch. News/Music switch.
Alarm clock and timer. Digital thermometer. SSB fine tuning.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 25 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 200x-20xx (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (6.9 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
