| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
TX: 6 m / 4 m (50-52 / 69.9-70.5 MHz)
RX: 50-52 / 69.9-70.5 MHz
|
| Tuning steps: | Down to 10 Hz |
| Frequency stability: | ±? ppm |
| Mode: | SSB / CW |
| Channels / memory management: |
10 regular per band
|
| Repeater shift / offset: | ±? |
| Power supply: | 11.5-14 VDC |
| Current drain / power consumption: | RX: ? mA
TX: Max 3.6 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 203*95*305 mm (7.99*3.74*12.01"), including projections |
| Weight: | 1.8 Kg (3.97 lb) |
| Other features: | Keyboard input. 10.7 MHz IF output. Built-in keyer. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 25 KHz
|
| Sensitivity: | -130 dBm (MDS) |
| Selectivity: | 500 Hz to 4 KHz adjustable with SCAF filters |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| Pwr |
|---|
| SSB (PEP): | 20 W |
| CW: | 20 W |
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 8-pin (Metal locking ring connector) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 2013-201x (Discontinued or never released?) |
| Additional info: |
Expected price 2013 is in the $800.00 range
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
