| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
30-50 / 144-174 / 450-470 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
16 regular (8 VHF + 8 UHF) @ 8 to 24 channels per second (Adjustable)
One XTAL per channel
|
| Power supply: | Mains: 115 VAC
or 12 VDC |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / Two ? |
| Dimensions (W*H*D): | 254*83*235 mm (10*3.25*9.25") |
| Weight: | 2.92 Kg (6.44 lb) |
| Other features: |
S-meter. Adjustable scan resume delay ("Memory").
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 1 uV (20 dB quieting) |
| Squelch sensitivity: | 0.4 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 1 W at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1974-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
