| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
30-50 / 150-170 / 450-512 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
10 regular
One XTAL per channel
|
| Power supply: | Mains: 120 VAC (Male 2-pin jack)
or 12 VDC (3-pin DIN jack) |
| Current drain / power consumption: | Less than 13 W @ 120 VAC
Less than 600 mA @ 12 VDC |
| Antenna impedance / connector: | 50 ohm / Two DIN41585 (Motorola) |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
