| GENERAL |
| Type: | UHF receiver/scanner |
| Frequency range: |
450-470 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
4 regular @ 12 channels per second
Channel 1 bypass switch
One XTAL per channel (HC-25U)
|
| Power supply: | 4.8-6 VDC (Four R6 / AA alkaline or NiCd batteries)
or 6 VDC external, TS "Minijack" (3.5 mm) |
| Current drain / power consumption: | 25-120 mA |
| Antenna impedance / connector: | 50 ohm / Threaded socket
or 50 ohm / TS "Subminijack" (2.5 mm) |
| Dimensions (W*H*D): | 70*136*35 mm (2.75*5.38*1.38") |
| Weight: | 283 g (10 oz), without batteries |
| Other features: | Charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (20 dB quieting) |
| Squelch sensitivity: | 0.5 uV (Threshold) |
| Noise figure: | |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | 60 dB |
| AF output power / speaker: | 250 mW at 10% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1974-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
18-106
18-112
18-243
|
AC adapter. 110-120 VAC to 6 VDC, 200 mA
Battery charger for in-unit recharging
Coil loaded UHF rubber antenna
|
|
