| GENERAL |
| Type: | UHF receiver/scanner |
| Frequency range: |
347-440 / 760-944 MHz
|
| Tuning steps: | 12.5 / 20 / 25 KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
15 regular
|
| Power supply: | 3.6 VDC (NiCd battery pack)
or 12 VDC external (Male barrel jack, center positive) |
| Current drain / power consumption: | 50 mA (Squelched) |
| Antenna impedance / connector: | 50 ohm / SMA |
| Dimensions (W*H*D): | 60*105*27 mm (2.36*4.13*1.06") |
| Weight: | 140 g (4.94 oz) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: |
0.2 uV (12 dB SINAD)
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 19xx-19xx (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
