| GENERAL |
| Type: | Marine VHF transceiver |
| Frequency range: |
TX: 155-159 MHz
RX: 155-159 / 159.6-163.6 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±10 ppm @ -20 to +55°C (-4 to +131°F) |
| Mode: | FM |
| Channels / memory management: |
55 international
15 private
Optional US channels
|
| Duplex shift / offset: | Automatic according to bandplan |
| Power supply: | 13.8 VDC (6-pin jack) |
| Current drain / power consumption: | RX: 600 mA (Squelched)
TX: Max 4.5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 160*56*210 mm (6.3*2.2*8.27") |
| Weight: | 2.5 Kg (5.51 lb) |
| Other features: | Channel 16 button. Dual watch. Dimmer. Selcall. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.3 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 4 W at 3% distortion / 4 ohm |
| External speaker connector: | 6-pin jack |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 25 W
Low: 1 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -80 dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 198x-198x (Discontinued) |
| Additional info: | |
| Related documents: | Service manual (5.5 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
