| GENERAL |
| Type: | License-free "902-928 MHz USA" transceiver |
| Frequency range: | 902-928 MHz |
| Channels / tuning steps: | ? |
| Frequency stability: | ±5 ppm @ -30 to +60°C (-22 to +140°F) |
| Mode: | DV (VSELP) with FHSS (90 ms hop rate, 50 frequencies per channel) |
| Memory channels / management: |
Contact list capacity:
Up to 10 private groups
Up to public groups
Max 150 private ID:s
|
| Repeater shift / offset: | Simplex only |
| Power supply: | 3.8 VDC (Li-Ion battery) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / SMA |
| Dimensions (W*H*D): | 57*132*35 mm (2.3*5.2*1.4") |
| Weight: | ? g (7.8 oz), with 1500 mAh battery |
| Other features: |
Full graphic display. Text messaging. Alarm clock.
Group and private calls. Vibralert. PC programmable. Cloning.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.13 uV (3% BER) |
| Squelch sensitivity: | - |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 1 W at 5% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | Max 1 W |
| Modulation system: | 8-level FSK |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 2012-201x (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (855 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
