| GENERAL |
| Type: | License-free "902-928 MHz USA" transceiver |
| Frequency range: | 902-928 MHz |
| Channels / tuning steps: |
6 regular "talk channels"
1 "home channel"
|
| Frequency stability: | ±1 ppm @ -30 to +60°C (-22 to +140°F) |
| Mode: | DV (VSELP) with FHSS (90 ms hop rate, 50 frequencies per channel) |
| Memory channels / management: | - |
| Repeater shift / offset: | Simplex only |
| Power supply: | 3.7 VDC (Li-Ion battery) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | Non-removable antenna |
| Dimensions (W*H*D): | 43*107*23 mm (1.7*4.2*0.9") |
| Weight: | 119 g (4.2 oz) |
| Other features: |
IP5X / IPX2 dust and water resistant. Voice prompt.
PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.13 uV (3% BER) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 750 mW at 5% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | Max 1 W |
| Modulation system: | 8-level FSK |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 2017-202x (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (92 MB, Multilanguage)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
HKLN4599
HKLN4601
HKLN4604
HKLN4606
HKLN4615
HKNN4013
PMLN7136
PMLN7140
|
Earpiece with in-line mike and PTT
Surveillance kit with in-line mike and PTT
Swivel earpice with in-line mike and PTT
Remote speaker-microphone
DLR belt clip holster
BT90 battery
12-pocket multi charger
Single-unit charger
|
|
