| GENERAL |
| Type: | HF receiver |
| Frequency range: |
0.55-30 MHz in five bands
| A: | 0.55-1.6 MHz |
| B: | 1.6-4.3 MHz |
| C: | 4.3-12 MHz |
| D: | 11-30 MHz |
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ±?% |
| Mode: | AM / CW |
| Channels / memory management: |
None
|
| Power supply: | Mains: 105-125 or 220-240 VAC (Depending on market) |
| Current drain / power consumption: | ? W |
| Antenna impedance / connector: | Hi-Z / Screw tertminals
Internal ferrite bar for MW |
| Dimensions (W*H*D): | 273*152*203 mm (10.75*6*8") |
| Weight: | 5.44 Kg (12 lb) |
| Other features: | S-meter. Logging scale. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion /? ohm |
| External speaker connector: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1965-1967 (Discontinued) |
| Additional info: |
3 tubes.
New price 1965 in the US: $49.95
New price, spring 1966 in the US: $49.95
New price, summer 1966 in the US: $39.95
New price, spring 1967 in the US: $44.95
New price, summer 1967 in the US: $39.95
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
