| GENERAL |
| Type: | Amateur HF transmitter |
| Frequency range: | 15 / 20 / 40 / 80 m |
| Tuning steps: | Analog / continuous |
| Frequency stability: | ±?% |
| Mode: | AM / SSB / CW |
| Channels / memory management: | |
| Power supply: | Mains: 100 VAC (Fixed power cord) |
| Current drain / power consumption: | Max ? W |
| Antenna impedance / connector: | 50-75 ohm / SO-239 |
| Dimensions (W*H*D): | 380*195*250 mm (15*7.68*9.84") |
| Weight: | 12 Kg (26.46 lb) |
| Other features: | VOX. |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
AM: 4 W
SSB/CW: 10 W
|
| Modulation system: | SSB: Balanced |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / TRS 1/4" jack |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1964-196x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
