| GENERAL |
| Type: | Amateur VHF (UHF) transceiver |
| Frequency range: |
USA and Canada
TX: 144-148 / 220-225 MHz
RX: 144-148 / 220-225 MHz
Band options
10 m, 6 m, 70 cm or 23 cm
|
| Tuning steps: | 5 / 10 / 12.5 / 15 / 20 / 25 KHz |
| Frequency stability: | ±10 ppm @ -20 to +60°C (-4 to +140°F) |
| Mode: | FM |
| Channels / memory management: |
100 regular per band (Can store odd splits)
1 call per band
RAM storage with lithium battery backup
|
| Repeater shift / offset: | 2 m: ±600 KHz
1.25 m: ±1.6 MHz |
| Power supply: | 13.8 VDC ±15% |
| Current drain / power consumption: | RX: Less than 1.2 A
TX: Less than 11.5 A |
| Antenna impedance / connector: | 50 ohm / ? (On pigtails) |
| Dimensions (W*H*D): | 150*50*175 mm (5.9*1.97*6.89") |
| Weight: | 1.5 Kg (3.31 lb), without optional band unit |
| Other features: |
CTCSS/PL encoder. DTMF. DTSS. Alarm clock with timer and stopwatch. Dimmer.
Crossband repeater. Twin RX (Triple RX with optional band module)
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz (2 m) - 30.825 MHz (1.25 m)
2nd IF: 455 KHz
|
| Sensitivity: | 0.16 uV (12 dB SINAD) |
| Selectivity: | 12 KHz (-6 dB)
24 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at 5% distortion / 8 ohm |
| External speaker connector: | 3.5 mm, 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Low 3 | Low 2 |
|---|
| 2 m: | 50 W | 10 W | 5 W |
| 1.25 m: | 25 W | 10 W | 5 W |
|
| Modulation system: | Reactance modulation |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | 600 ohm / 8-pin (Modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 199x-199x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (3.6 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
DFK-3
DFK-4
DFK-7
MB-14
MC-44
MC-44DM
MC-44DME
MC-44E
MJ-88
MJ-89
PG-3B
PG-3G
PS-33
SP-41
SP-50B
TSU-7
UT-28S
UT-50S
UT-440S
UT-1200
|
Detachable front panel mounting kit. 3 m (? ft)
Detachable front panel mounting kit. 4 m (? ft)
Detachable front panel mounting kit. 7 m (? ft)
Mobile mounting bracket
Multifunction microphone
Multifunction microphone with autopatch
Multifunction microphone with autopatch (Europe)
Multifunction microphone (Europe)
Modular to 8-pin microphone adapter
Modular plug microphone switch
Noise filter power cable
DC cable
Power supply. 13.8 VDC, 20.5 A
Mobile speaker
Communications speaker
CTCSS/PL decoder unit
10 m / 50 W band unit
6 m / 50 W band unit
70 cm / 35 W band unit
23 cm / 10 W band unit
|
|
