Heathkit HW-30 (The "Twoer", a.k.a. "The Benton Harbor Lunchbox")

A picture of Heathkit HW-30 (The ''Twoer'', a.k.a. ''The Benton Harbor Lunchbox'')

SPECIFICATIONS

GENERAL
Type:Amateur VHF transceiver
Frequency range: TX: 144-148 MHz
RX: 144-148 MHz
Tuning steps:Analog / continuous
Frequency stability:? ppm
Mode:AM
Channels / memory management: One XTAL controlled for TX
Repeater shift / offset:No
Power supply:Mains
Current drain / power consumption:RX: ? mA
TX: Max ? A
Antenna impedance / connector:50 ohm / SO-239
Dimensions (W*H*D):245*169*131 mm (9.65*6.65*5.16")
Weight:? Kg (? lb)
Other features:




RECEIVER SECTION
Receiver system: Superregenerative detector
Sensitivity:1 uV (No reference)
Selectivity:
Image rejection:
AF output power / speaker:? W at ?% distortion / ? ohm
External speaker connector:




TRANSMITTER SECTION
RF output power: 5 W (Input)
Modulation system:
Max FM deviation (Factory set):No FM
Spurious emissions:Better than -? dB
Microphone impedance / connector:? ohm / ?-pin
Microphone input level:? mV




MISCELLANEOUS
Manufactured:USA, 1960-1971 (Discontinued)
Additional info:New price 1961: $44.95
Related documents:
Modifications and fixes:
Reviews:
Options / Accessories:
- -
