| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 76-180 / 230-250 / 350-512 / 700-960 MHz
|
| Tuning steps: | TX: Channelized
RX: 2.5 / 5.0 / 6.25 / 10 / 12.5 / 25 / 50 / 100 KHz |
| Frequency stability: | ±2.5 ppm @ -20 to +40°C (-4 to +104°F) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
870 user programmable
Alpha tags
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / SMA female |
| Dimensions (W*H*D): | 61*124*34 mm (2.4*4.88*1.34") |
| Weight: | 490 g (1.08 lb) |
| Other features: |
CTCSS/PL and DCS with tone scan. DTMF. LED flashlight.
Voice guide. IP55 waterproof. Dual PTT. VOX.
PC programmable. Twin RX.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.25 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: |
FM: 70 dB (Adjacent channel)
NFM: 60 dB (Adjacent channel)
|
| Image rejection: | |
| AF output power / speaker: | 500 mW at 5% distortion / ? ohm |
| External speaker connector: | TRS "Subminijack" (2.5 mm), K-Type |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 5.5 W | 2 W | 500 mW |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | ? ohm / TRS "Minijack" (3.5 mm), K-Type |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2021-2022 (Discontinued) |
| Additional info: | |
| Related documents: |
Generic user manual (9.5 MB)
G Pro addendum (4.5 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
BLO-012
|
Li-Ion battery pack. 7.4 V, 3200 mAh
|
|
