| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 26.965-27.405 / 76-108 / 108-174 / 222-225 / 320-480 / 714-999 MHz
|
| Tuning steps: | TX: Channelized
RX: 2.5 / 5.0 / 6.25 / 8.33 / 10 / 12.5 / 25 / 50 / 100 KHz |
| Frequency stability: | ±2.5 ppm @ -20°C to +40°C (-4 to +104°F) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
7 NOAA weather channels
40 CB channels
999 user programmable
Alpha tags
Scanning
Priority function
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / SMA male |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | 312 g (11.01 oz) |
| Other features: |
CTCSS/PL and DCS with tone scan. DTMF. NOAA weather alert.
GPS positioning and sharing. USB-C charging. 10 display color themes
plus 4 custom themes. VOX. SOS feature. Voice guide. LED flashlight.
Clock and stopwatch. IP67 waterproof. Roger beep. Cloning.
PC programmable. Twin RX.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: |
AM (12 dB S/N)
108-136 MHz: 1.12 uV
FM (12 dB SINAD)
136-174 MHz: 0.25 uV
216-260 MHz: 0.35 uV
400-480 MHz: 0.25 uV
714-999 MHz: 3.55 uV
|
| Squelch sensitivity: | |
| Selectivity: |
FM: -70 dB (Adjacent channel)
NFM: -60 dB (Adjacent channel)
|
| Image rejection: | |
| AF output power / speaker: | 500 mW at 5% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| Ultra high | High | Mid | Low |
|---|
| 6 W | 4 W | 2 W | 500 mW |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2024-202x |
| Additional info: |
New price, october 2025 in the US: $219.99
|
| Related documents: | User manual (1.5 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
BLO-032
|
Li-Ion battery pack. 7.4 V
|
|
