| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 50-54 / 108-180 / 320-350 / 400-480 / 700-985 MHz
|
| Tuning steps: | TX: Channelized
RX: 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 / 100 KHz |
| Frequency stability: | ±5 ppm @ -20 to +40°C (-4 to +104°F) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
7 NOAA weather channels
962 user programmable
Alpha tags
Scanning
Priority function
|
| Repeater capable: | Yes |
| Power supply: | 13.8 VDC ±15% |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 140*44*207 mm (5.5*1.73*8.15") |
| Weight: | 1.4 Kg (3.09 lb) |
| Other features: |
CTCSS/PL and DCS with tone scan. DTMF. NOAA weather alert.
Tone call. Descrambler. Voltmeter. Roger beep. Voice guide.
Twin RX.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: |
FM (12 dB SINAD)
50-54 MHz: 0.25 uV
136-174 MHz: 0.25 uV
320-350 MHz: 0.25 uV
400-480 MHz: 0.25 uV
700-985 MHz: 3.16 uV
|
| Squelch sensitivity: | |
| Selectivity: |
FM: 70 dB (Adjacent channel)
NFM: 60 dB (Adjacent channel)
|
| Image rejection: | |
| AF output power / speaker: | 3 W at 5% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid1 | Mid2 | Low |
|---|
| 50 W | 25 W | 10 W | 5 W |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | ? ohm / 8-pin (RJ45 modular jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2023-202x |
| Additional info: |
FCC ID: WVTWOUXUN20
New price, october 2025 in the US: $389.99
|
| Related documents: | User manual (4.3 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
