| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 50-76 / 76-108 / 108-600 MHz
|
| Tuning steps: | TX: Channelized
RX: 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 50 KHz |
| Frequency stability: | ±2.5 ppm @ -20 to +50°C (-4 to +122°F) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
10 NOAA weather channels
169 user programmable
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: Less than 380 mA
TX: Less than 1.5 A |
| Antenna impedance / connector: | 50 ohm / ? |
| Dimensions (W*H*D): | 53*112*32 mm (2.08*4.4*1.26") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. DTMF. Off-air frequency copy. VOX.
USB-C charging. Dual PTT. Dual watch. LED flashlight.
Scrambler. Roger beep. Bluetooth. Voice guide.
PC and app programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.25 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 55 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 1 W at 5% distortion / 16 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2024-20xx |
| Additional info: |
FCC ID: 2A4FBTD831G
New price, october 2025 in the US: $22.99
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
