| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 65-108 / 108-174 / 220-260 / 350-390 / 400-520 MHz
|
| Tuning steps: | TX: Channelized
RX: 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 50 / 100 KHz |
| Frequency stability: | ±2.5 ppm @ -10 to +60°C (14 to 140°F) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
970 user programmable
10 NOAA weather channels
10 zones
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 50 ohm / SMA male |
| Dimensions (W*H*D): | 64*143*41 mm (2.5*5.6*1.6") |
| Weight: | 298 g (10.5 oz), with battery |
| Other features: |
CTCSS/PL and DCS. DTMF. One-click frequency copy.
VOX. USB-C charging. GPS tracking and location sharing.
LED flashlight. Voice guide. Roger beep. Dual watch.
Scrambler. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC / Homodyne (Direct conversion)
|
| Sensitivity: | 0.22 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 750 mW at 5% distortion / 16 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -16 dBm |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2024-202x |
| Additional info: |
FCC ID: 2AN62-GM30PLUS
New price, october 2025 in the US: $36.99
|
| Related documents: | User manual (1.7 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
