| GENERAL |
| Type: | GMRS / FRS dual standard transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-162.000 / 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | NFM |
| Channels / memory management: |
22 regular
11 NOAA weather channels
Scanning
|
| Repeater capable: | No |
| Power supply: | 3.6-4.5 VDC (Three LR6 / AA alkaline batteries or NiMH pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. VOX. NOAA weather alert.
Roger beep. 10 call tones. Vibralert.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 450 KHz - Ceramic filter: CFT450HT
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2007-20xx (Discontinued) |
| Additional info: |
Main PCB: KEPC-1037-T2 by ?
FCC ID: K7GT9500
New price, august 2007 in the US: $69.95 (Set of two units)
|
| Related documents: | User manual (6.4 MB) |
| Modifications and fixes: | |
| Reviews: | Popular Communications: August 2007, page 39 |
| Options / Accessories: |
|
