| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-163.275 / 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | FM / NFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
28 CTCSS/PL preset
10 NOAA weather channels
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 3.6-4.5 VDC (Three LR6 / AA alkaline batteries or Li-Ion pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. Dual watch. NOAA weather alert.
LED flashlight. Roger beep. Vibrate alert. VOX.
USB-C charger. SOS siren. Whisper function.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 2.5 W | ? W | 500 mW |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines, 2023-202x |
| Additional info: |
New price, october 2025 in the US: $149.99 (Value pack 4, two units)
FCC ID: MMAGXT3000
|
| Related documents: | User manual (36 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AVP1
AVPH2
AVPH3
AVPH4
AVPH5
AVPH7
AVPH8
AVPH10
BATT18R
|
Over the ear headsets
Closed face helmet headset kit
SSurveillance headset
Wrap around the ear headsets
Behind the head headsets
Camo headsets with boom mic
Acoustic throat mic
Speaker-microphone
Li-Ion battery pack. 3.7 V, 1800 mAh
|
|
