| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-163.275 / 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±? ppm |
| Mode: | FM / NFM |
| Channels / memory management: |
All GMRS/FRS channels in various configurations in bank 1, 2 and 3
Bank 4 stores channels from the Find function
10 NOAA weather channels
Scanning
|
| Repeater capable: | Yes |
| Power supply: | ? VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / SMA |
| Dimensions (W*H*D): | 61*221*38 mm (2.41*8.7*1.51"), with antenna |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL and DCS. USB-C charging and programming. VOX.
Find function (Frequency copy). Weather alert. Flashlight.
Roger beep. 10 call tones. Emergency alert. IP54 waterproof.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC / Homodyne (Direct conversion)
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Max 2.5 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Vietnam, 2025-202x |
| Additional info: |
New price, april 2026 in the US: $109.95 (2-pack).
|
| Related documents: |
User manual (2.2 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
