| GENERAL |
| Type: | GMRS / FRS dual standard transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 161.650-163.275 / 462 / 467 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±500 Hz (No temperature reference) |
| Mode: | NFM |
| Channels / memory management: |
8 GMRS
7 FRS
7 shared GMRS/FRS
10 NOAA weather channels
10 user programmable
Scanning
|
| Repeater capable: | No |
| Power supply: | 4.2-6 VDC (Four R6 / AA alkaline or rechargeable batteries) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL. NOAA WX alert. Digital compass. Alarm clock.
Stopwatch. VOX. Vibralert. 10 call tones. Roger beep.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.2 uV (12 dB SINAD) |
| Squelch sensitivity: | 0.2 uV (Threshold) |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 200 mW at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2002-200x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (2.7 MB) |
| Modifications and fixes: | |
| Reviews: | Popular Communications: December 2004, page 35 |
| Options / Accessories: |
|
