| GENERAL |
| Type: | GMRS transceiver |
| Frequency range: |
TX: 462 / 467 MHz
RX: 65-108 / 108-136 / 136-174 / 220-260 / 350-390 / 400-520 MHz
|
| Tuning steps: | TX: Channelized
RX: 2.5-100 KHz |
| Frequency stability: | ±2.5 ppm @ -10 to +60°C (14 to 140°F) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
22 GMRS simplex
8 GMRS repeater
1000 custom in 10 zones/banks
10 NOAA weather channels
Alpha tags
Scanning
|
| Repeater capable: | Yes |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 50 ohm / SMA male |
| Dimensions (W*H*D): | 67*182*41 mm (2.6*7.2*1.6") |
| Weight: | 350 g (12.3 oz) |
| Other features: |
2" color display. CTCSS/PL and DCS with tone scan.
NOAA weather alert. USB-C battery. Nearfield frequency
counter. Built-in GPS with location sharing. Roger beep.
USB or Bluetooth programming. VOX. Twin RX.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.22 uV (No SINAD reference) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 750 mW at 5% distortion / 16 ohm |
| External speaker connector: | TRS "Subminijack" (2.5 mm). K1 type |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM (Wide): ±5 KHz
NFM (Narrow): ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / TRS "Minijack" (3.5 mm). K1 type |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2026-202x |
| Reset procedure: | |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
