| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 58-88 / 118-136 / 144-174 / 380-512 MHz |
| Tuning steps: | ? / ? KHz |
| Mode: | AM/FM |
| Channels/memory management: | 50 regular @ 20 ch/sec |
| Power supply: | 13.8 VDC |
| Current drain/power consumption: | ? mA |
| Antenna impedance/connector: | 50-75 ohms / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 150*63*200 mm (5.91*2.48*7.87") |
| Weight: | ? Kg (? lbs) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: | Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz |
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power/speaker: | ? W at ?% distortion / ? ohms |
| External speaker connector: | 3.5 mm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1982-198x (Discontinued) |
| Additional info: | New price 1983 in Sweden: 2965:- SEK |
| Related documents: | |
| Modifications: | |
| Options/Accessories: |
|
