| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: | 68-98 MHz |
| Tuning steps: | Channelized
Programmable in 1 / 100 KHz, 1 / 10 MHz steps |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
20 regular
1 priority
|
| Power supply: | ? VDC |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | ? ohm / TS "Minijack" (3.5 mm) |
| Dimensions (W*H*D): | 65*122*32 mm (2.56*4.8*1.26") |
| Weight: | 260 g (9.17 oz), with batteries |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.4 uV (No SINAD reference) |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 100 mW at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1983-198x (Discontinued) |
| Additional info: |
New price 1983 in Sweden: SEK 1670:-
New price 1990 in Sweden: SEK 1960:-
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
