| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: | 75-88 MHz |
| Tuning steps: | Channelized |
| Frequency stability: | 0.001% @ -20 to +50°C ( |
| Mode: | FM |
| Channels / memory management: |
10 regular @ 10 channels per second
2.5 second scan resume delay (Squelch controlled)
XTAL controlled
|
| Power supply: | 4.8 VDC (NiCd pack)
or 6 VDC external |
| Current drain / power consumption: | ? mA @ 4.8 VDC |
| Antenna impedance / connector: | ? ohm / Threads
SO-239 option |
| Dimensions (W*H*D): | 69*112*33 mm (2.71*4.41*1.3") |
| Weight: | 240 g (8.5 oz), with NiCd battery pack |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (No SINAD reference) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 8 ohm |
| External speaker connector: | TS "Subminijack" (2.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1980-198x (Discontinued) |
| Additional info: |
New price 1981 in Sweden: SEK 535:- (Without XTALs)
New price 1982 in Sweden: SEK 594:- (Including 7 XTALs)
|
| Related documents: |
User manual (3.3 MB)
FM-IF: MC3357
AF amplifier: NJM386
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
367
|
Mobile holder/charger with SO-239 jack
|
|
