| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
6 m: 49.9-52.1 MHz
|
| Tuning steps: | Continuous |
| Frequency stability: | Less than 3 KHz per hour after warmup |
| Mode: | AM |
| Channels / memory management: |
|
| Repeater shift / offset: | No |
| Power supply: | Mains: 117 VAC
or 13.8 VDC |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 52 ohm / SO-239 |
| Dimensions (W*H*D): | 305*165*305 mm (12*6.5*12") |
| Weight: | 8.62 Kg (19 lb) |
| Other features: | XTAL for TX (VFO option). |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 456 KHz
|
| Sensitivity: | 0.35 uV (10 dB S+N/N) |
| Selectivity: | 8 KHz (No reference) |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| Max pwr |
|---|
| 6 m: | ~13 W (22 W input) |
|
| Modulation system: | High level with speech clipping |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -66 dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1966-196x (Discontinued) |
| Additional info: | New price, july 1966 in the US: $249.95 |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | 73 Magazine: April 1967, page 90 |
| Options / Accessories: |
|
