| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26-31 MHz (Align to any 300 KHz segment) |
| Channels / tuning steps: | 6 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Eight R6 / AA batteries or NiCd pack)
or 12 VDC external (Male barrel jack, center positive) |
| Current drain / power consumption: | RX: 30 mA
TX: 600 mA |
| Antenna impedance / connector: | Built-in telescopic whip
or 50 ohm / Phono (RCA) |
| Dimensions (W*H*D): | 80*250*55 mm (3.15*9.84*2.16") |
| Weight: | 1.75 Kg (3.86 lb), with batteries |
| Other features: | Battery/power/S-meter. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 0.5 uV (10 dB S/N) |
| Squelch sensitivity: | 6 KHz (-6 dB)
20 KHz (-28 dB) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2.5 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Hi: ~3 W (5 W input)
Lo: ~1.2 W (2 W input)
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 19xx-19xx (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Known markets and approvals: |
Sweden
Kungliga Telestyrelsen
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options/Accessories: |
BE-1A
BL
DC-2
FA-27
FA-29
GFA
M
MH-1
MH-2
SA-1
|
AC power supply and charger. 220 VAC
AC charger. 220 VAC
DC/DC-converter. 6 to 12 V
Stick-on antenna. 27 MHz
Stick-on antenna. 29 MHz
Stick-on fibreglass antenna
Hand microphone
Earpiece-microphone
Headset and microphone
DC stabilizer for 12 V car battery
|
|
