| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26-31 MHz |
| Channels / tuning steps: | 1 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Eight R6 / AA alkaline batteries or NiCd pack)
or 12 VDC external |
| Current drain / power consumption: | RX: 12 mA
TX: 50 mA |
| Antenna impedance / connector: | Built-in telescopic whip
or 50 ohm / Phono (RCA) |
| Dimensions (W*H*D): | 90*210*40 mm (3.54*8.27*1.57") |
| Weight: | 1 Kg (2.2 lb), with batteries |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 0.8 uV (10 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 250 mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~300 mW (500 mW input) |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1967-196x (Discontinued) |
| Main PCB: |
New price, july 1967 in Sweden: SEK 445:- + VAT
|
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Known markets and approvals: |
Sweden
Kungliga Telestyrelsen
Finland
?
Norway
?
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
BE-0.2A
BE-1A
BL
FA-27
FA-29
GFA
M
MH-1
MH-2
|
AC power supply. 220 VAC
AC power supply and charger. 220 VAC
Charger. 220 VAC
Stick-on antenna. 27 MHz
Stick-on antenna. 29 MHz
Stick-on fibreglass antenna
Hand microphone
Earpiece-microphone
Headset with microphone
|
|
