| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: |
Standard
26.865-27.265 MHz
Export mode
26.515-27.865 MHz
|
| Channels / tuning steps: | 34 (Standard)
120 (Export mode) |
| Mode: | AM / FM |
| Frequency control: | PLL |
| Frequency stability: | ±0.005% |
| Clarifier or Delta tune: | No |
| Power supply: | 12.6 VDC ±10% (Male 3-pin jack) |
| Current drain / power consumption: | RX: 0.5-1 A
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 165*55*205 mm (6.5*2.16*8.07") |
| Weight: | 1.65 Kg (3.64 lb) |
| Other features: | PA. ANL/NB. AWI (SWR warning). |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM: 0.5 uV (10 dB S+N/N)
FM: ? uV (12 dB SINAD)
|
| Squelch sensitivity: | |
| Selectivity: | 3 KHz (-6 dB) ? |
| Image rejection: | 50 dB |
| AF output power / speaker: | 4 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
4 W (Standard)
10 W (Export mode)
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±2 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Male locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 20xx-202x |
| Main PCB: |
Double sided with mainly SMD components
|
| Sub PCBs: | |
| Additional info: |
This is the modern version of Midland/Alan 68S
New price 2020 in Italy: 228.99 Euro incl. VAT
|
| Related documents: | |
| Market(s) / Approval(s): |
Italy (Standard only)
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
