| GENERAL |
| Type: | Citizen band / Freeband / Export transceiver |
Frequency range
depending on setting: |
Standard
26.965-27.405 MHz (E1: Europe)
26.965-27.405 MHz (EC: Europe, FM only)
26.965-27.405 MHz (EU: Europe)
26.565-27.405 MHz (DE: Germany)
26.965-27.405 MHz (I1: Italy)
26.875-27.265 MHz (I2: Italy)
26.960-27.400 MHz (PL: Poland)
27.60125-27.99125 MHz (UK: United Kingdom, FM only)
26.965-27.405 MHz (US: USA)
Export mode
24.500-26.495 MHz (12h: 12 m amateur band)
28.000-29.700 MHz (10: 10 m amateur band)
25.615-30.105 MHz (HF: General export mode)
26.965-27.855 MHz (BR: Brazil, export mode)
25.610-30.100 MHz (PL400: Poland, export mode)
|
Channels / tuning steps
depending on setting: |
Standard: 34, 40 or 80
Export mode: Up to 400 + Alphas
|
| Mode: | AM / FM / SSB / CW |
| Frequency control: | PLL/CPU |
| Frequency stability: | ±5 ppm @ -10 to +55°C (14 to 131°F) |
| Clarifier or Delta tune: | ±? KHz |
| Power supply: | 12.6 VDC ±10% (Male 3-pin jack) |
| Current drain / power consumption: | RX: Less than 800 mA
TX: Less than 6 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 175*55*135 mm (6.89*2.16*5.31") |
| Weight: | 1.2 Kg (2.64 lb) |
| Other features: |
PA. CTCSS/PL and DCS. DSP noise reduction. Echo. Programmable roger beep.
Tone hi-cut. Channel 9/19 button. Scanning. Dual watch. 7 selectable display
colors. VOX. Dimmer. ASQ. SWR protection. Repeater shift. +10 KHz button.
Voltage warning. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | <1 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Standard
AM: 4 W (Carrier/dead key)
FM: 4 W
SSB: 12 W (PEP)
Export mode
AM: 10 W (Carrier/dead key)
FM: 35 W
SSB: 40 W (PEP)
NB! The output power is adjustable down to about 1 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±1.9 KHz |
| Spurious emissions: | Better than -54 dBm |
| Microphone impedance / connector: | ? ohm / 6-pin (Male locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2026-202x |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price, march 2026 in Germany: €299.00
New price, march 2026 in Sweden: SEK 3495:-
|
| Related documents: |
User manual (2.2 MB)
|
| Known markets and approvals: |
Europe (Standard)
Multinorm
Export mode
No known approvals
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
