| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 23 |
| Mode: | AM |
| Frequency control: | XTAL matrix (14 XTALs) |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | 9.6-12 VDC (Eight R6 / AA alkaline or NiCd batteries)
or 12 VDC external |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | Built-in telescopic whip
or 50 ohm / Phono (RCA) |
| Dimensions (W*H*D): | 83*248*57 mm (3.25*9.75*2.25") |
| Weight: | 1.47 Kg (3.25 lb) |
| Other features: | PA. S/PWR/Battery meter. Charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ~10.6 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 1 uV (6 dB S/N) |
| Squelch sensitivity: | 1 uV (Threshold) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 500 mW at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3.5 W (5 W input) |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | 8 ohm / Built-in
or ? ohm / TS "Minijack" (3.5 mm) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1969-197x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: | User manual (1.4 MB) |
| Market(s) / Approval(s): |
USA
FCC: Part 19 / 95 compliant
|
| Sams Photofact #: | CB-26 (February 1970) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
18-136
18-137
18-138
18-143C
18-210
|
DC cable with cigarette lighter plug
External battery pack with shoulder strap (Eight LR20 / D batteries)
External microphone
AC power supply and charger
External antenna for mobile or base use
|
|
