| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 3 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Eight R6 / AA alkaline or ten NiCd batteries)
or 12 VDC external (Male barrel jack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | Fixed telescopic whip
50 ohm / RCA (Phono) |
| Dimensions (W*H*D): | 83*221*48 mm (3.25*8.69*1.88") |
| Weight: | 770 g (1.7 lb) |
| Other features: | Charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 1 uV (10 dB S+N/N) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 16 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: ~3.5 W (5 W input)
Low: ~1.2 W (2 W input)
|
| Modulation system: | |
| Max AM modulation (Factory set): | 90 to 100% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | 16 ohm / TS "Minijack" (3.5 mm) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1975-1976 (Discontinued) |
| Main PCB: |
EPO-0635 by Cybernet Electronics Corporation
|
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Known markets and approvals: |
USA
FCC: Type accepted class D, vol. 6, part 95
|
| Sams Photofact #: | CB-76 (November 1975) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
22-225
|
Speaker-microphone (No PTT)
|
|
