| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 12 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Male 3-pin jack) |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 135*53*201 mm (5.3*2.1*7.9") |
| Weight: | ? Kg (? lb) |
| Other features: | PA. Priva-Com selcall jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.7 uV (10 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3.5 W (5 W input) |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin "Y-jack" |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1965-196x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1966 in the US: $99.95
New price 1967 in the US: $89.95
|
| Related documents: | |
| Market(s) / Approval(s): |
Canada
D.O.T: 169361093
USA
FCC
|
| Sams Photofact #: |
CB-10 (March 1966)
CB-15 (September 1967)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
