| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 23 |
| Mode: | AM |
| Frequency control: | XTAL matrix |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | Mains: 117 VAC
or 12 VDC |
| Current drain / power consumption: | RX: ? W
TX: ? W |
| Antenna impedance / connector: | 30-100 ohm / SO-239 |
| Dimensions (W*H*D): | 305*127*216 mm (12*5*8.5") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 1.65 MHz
2nd IF: 282 KHz
|
| Sensitivity: | Less than 1 uV (10 dB S/N) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3.5 W (5 W input) |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1963-196x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price, october 1963 in the US: $159.50
|
| Related documents: | |
| Market(s) / Approval(s): |
USA
FCC
|
| Sams Photofact #: | CB-6 (September 1964) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
HA-100
|
Priva-Com dual tone selcall unit
|
|
