| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 3 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | ? VDC (NiCd battery pack)
or 12 VDC external |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | - / Fixed telescopic whip
50 ohm / ? |
| Dimensions (W*H*D): | 82*260*57 mm (3.25*10.25*2.25") |
| Weight: | ? Kg (? lb) |
| Other features: |
Battery/RF power meter. "Range boost".
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 1 uV (10 dB S+N/N) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3.5 W (5 W input) |
| Modulation system: | Push-pull |
| Max AM modulation (Factory set): | Near 100% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / Internal only |
| Microphone input level: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1967-1969 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1967 in the US: $99.95 (With XTALs for channel 10)
New price 1968 in the US: $79.95 (With XTALs for channel 10)
New price 1969 in the US: $79.95 (With XTALs for channel 10)
|
| Related documents: | |
| Known markets and approvals: |
Canada
DOT No: 169 361 116
USA
FCC: Type accepted, Part 95, class D
|
| Sams Photofact #: | CB-16 (June 1968) |
| Modifications and fixes: | |
| Reviews: | |
| Options/Accessories: |
|
