| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 23 |
| Mode: | AM / SSB |
| Frequency control: | XTAL matrix |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | ±? KHz "Fine tuning" |
| Power supply: | Mains: 120 VAC
or 13.8 VDC |
| Current drain / power consumption: | RX: ? mA @ 13.8 VDC
TX: ? A @ 13.8 VDC |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 241*83*260 mm (9.5*3.25*10.25") |
| Weight: | ? Kg (? lb) |
| Other features: |
PA. ANL. Built-in flip down stand for base use.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: |
AM: 0.5 uV (10 dB S/N)
SSB: 0.12 uV (10 dB S/N)
|
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | TS 1/4" jack |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
AM: ~3.5 W (5 W input)
SSB: ~10 W PEP (15 W PEP input)
|
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Male GX16 locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1974-1976 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1974 in the US: $339.00
New price 1975 in the US: $299.00
New price 1976 in the US: $319.00
New price 1977 in the US: $194.00
|
| Related documents: | |
| Known markets and approvals: |
USA
FCC Data: 981-6240A
|
| Sams Photofact #: | CB-74 (October 1975) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
