| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels/tuning steps: | 3 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: |
12 VDC (Eight R6 / AA alkaline or ten NiCd batteries)
or 12 VDC external (Male barrel jack)
|
| Current drain/power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance/connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 76*241*54 mm (2.99*9.49*2.13") |
| Weight: | ? g (? lb) |
| Other features: | Battery meter. Charger jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 1 uV (No S/N reference) |
| Squelch sensitivity: | |
| Selectivity: | 10 KHz (-30 dB) |
| Image rejection: | |
| AF output power/speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~1.2 W (2 W input) |
| Modulation system: | |
| Max AM modulation (Factory set): | 100% |
| Max FM deviation: | No FM |
| Spurious emissions: | Less than -? dB |
| Microphone impedance/connector: | ? ohm / "Minijack" (3.5 mm) |
| Microphone input sensitivity: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1981-198x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1982 in Sweden: SEK 595:-
|
| Related documents: | |
| Known markets and approvals: |
Sweden
Televerket: RL ?
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options/Accessories: |
|
