| GENERAL |
| Type: | Citizen band / "Freeband" / Export transceiver |
| Frequency range: |
26.965-27.405 MHz (Standard)
25.165-29.655 MHz (Export mode)
|
| Channels / tuning steps: | 40 (Standard)
400 (Export mode) |
| Mode: | AM |
| Frequency control: | PLL/CPU (LC7232) |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | Mains: 120 VAC
or 13.8 VDC (Barrel connector, center positive) |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 300*85*240 mm (11.8*3.35*9.45") |
| Weight: | ? Kg (? lb) |
| Other features: | ANL/NB. Channel 9/19 button. Dual watch. 4 memories. Scanning. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | 3.5 mm, 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 4 W |
| Modulation system: | |
| FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Metal locking ring connector) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines, 1998-200x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
After pressure from the FCC, later version had the modification
area sealed with epoxy to prevent frequency conversion.
FCC ID: MGPCBS-500
New price 1998 in the US: $199.95 (MSRP)
|
| Related documents: | PLL/CPU: LC7232 |
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
