| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
Europe
25-520 / 758-960 / 1240-1300 MHz
|
| Tuning steps: | 2.5 / 3.25 / 5 / 6.25 / 7.5 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz |
| Frequency stability: | ? ppm |
| Mode: |
Analog:
AM / FM / NFM / WFM / FMB
DV modes:
| DMR / MotoTRBO | C4FM | AMBE+2 |
| dPMR | C4FM | AMBE+2 |
| NXDN / DCR | C4FM | AMBE+2 |
|
| Channels / memory management: |
1000 regular in 10 banks with alpha tags
10 custom search ranges
23 service search ranges
Priority function
|
| Power supply: | 11-16.6 VDC (Male barrel jack, center positive or male 3-pin jack) |
| Current drain / power consumption: | Max 230 mA (Squelched)
Max 540 mA (Full audio) |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 184*56*151 mm (7.24*2.2*5.94") |
| Weight: | 1.5 Kg (3.2 lb), without mounting bracket |
| Other features: |
Backlit dot matrix LCD, 128*64 pixels. Custom alerts. S meter.
CTCSS/PL and DCS decoder. Band scope. 20 dB attenuator.
DMR color code. NXDN area or RAN code display. IF exchange.
Record out. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
AM (12 dB SINAD)
25.005 MHz: 0.49 uV
118.800 MHz: 0.35 uV
127.175 MHz: 0.36 uV
135.500 MHz: 0.36 uV
225.050 MHz: 0.36 uV
272.950 MHz: 0.37 uV
315.050 MHz: 0.37 uV
325.050 MHz: 0.35 uV
FM (12 dB SINAD)
72.515 MHz: 0.26 uV
NFM (12 dB SINAD)
40.840 MHz: 0.36 uV
53.980 MHz: 0.33 uV
138.150 MHz: 0.32 uV
161.985 MHz: 0.35 uV
173.225 MHz: 0.36 uV
216.020 MHz: 0.29 uV
406.875 MHz: 0.28 uV
511.9125 MHz: 0.29 uV
758.0125 MHz: 0.33 uV
806.000 MHz: 0.34 uV
857.150 MHz: 0.31 uV
954.9125 MHz: 0.3 uV
1299.925 MHz: 0.48 uV
WFM (12 dB SINAD)
54.050 MHz: 0.73 uV
197.450 MHz: 0.66 uV
FMB (12 dB SINAD)
107.500 MHz: 0.53 uV
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2.6 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Vietnam, 2025-202x |
| Additional info: |
New price, may 2026 in Sweden: SEK 5595:-
|
| Related documents: |
User manual (2.5 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
ARC260
|
Programming software
|
|
